How can one failed wall bring down a whole corner of a tower?

In 1968 a small gas explosion on the 18th floor brought down a whole corner of a 22-storey London tower, killing four people, and changed how buildings are designed.

▶ Start the story

A tall building is supposed to be a team: if one part fails, the others should pick up its load. Ronan Point in East London showed what happens when they cannot. On 16 May 1968, a gas explosion in an 18th-floor corner flat blew out a load-bearing wall, and one entire corner of the 22-storey tower collapsed. Four people died and 17 were injured. Engineers call this progressive collapse: a primary structural element fails, the failure spreads to adjoining elements, and the damage ends up out of proportion to the original cause.

At about 5:45 am, resident Ivy Hodge went into her kitchen to make a cup of tea and lit a match for her gas stove. Gas had been leaking, and the match sparked an explosion that blew out the flank wall, a wall that had been supporting the four flats above. With it gone, the floors above her living room were unsupported and fell, and the falling slabs stacked onto the floors below. The tower had only been open for two months.

How one wall became a corner
  1. Step 1: A match lights a gas leak

    18th-floor corner flat, about 5:45 am

  2. Step 2: The explosion blows out a flank wall

    A wall that supported the four flats above

  3. Step 3: Floors above lose their support

    They fall

  4. Step 4: Slabs stack onto the floors below

    A progressive collapse down the corner

The cause of the gas leak was small: a cracked nut on the stove's connection, believed to have been overtightened. But the failure was not. An investigation found that the connection between floor slabs and flank walls had not been designed to cope with the changes in load from forces such as an explosion or high winds. The low death toll is thought to be due to the early hour, when most residents were in their bedrooms rather than the living rooms that collapsed. Hodge herself survived, knocked unconscious in her kitchen by the blast.

The consequences ran far beyond one tower. Britain changed its building regulations so that, in an accident, a building must not suffer collapse out of proportion to the cause, and many other countries have since done the same. Public confidence in the safety of tall residential blocks was irreparably shaken.

Quiz me

0/3

  1. 1.What does 'disproportionate collapse' mean?
  2. 2.What did the investigation find about the connections at Ronan Point?
  3. 3.Which of these is an alternative load path approach?

Recap

A robust building is not one that never fails but one that can lose a part without losing a corner.

💡 A trick to remember it · Strong is carrying the load; robust is having a plan B when a piece goes missing.

Surprising fact · A cracked nut on a gas stove and badly attached joints were enough to bring down the corner of a 22-storey tower.
