How do you dig the world's longest railway tunnel through the Alps?

The Gotthard Base Tunnel runs up to 2,450 metres under the mountains, where the rock can reach 46 degrees Celsius.

โ–ถ Start the story

You do not dig it from two ends: you attack it from many places at once. To cut construction time in half, four access tunnels were built so that digging could start at four different sites at the same time: Erstfeld, Amsteg, Sedrun and Faido. At Sedrun, a 1 km access tunnel leads to two vertical shafts that go 800 metres down to the level of the base tunnel. The result is the Gotthard Base Tunnel in Switzerland, which opened in June 2016 and, at 57.09 km, became the world's longest railway tunnel (as of 2016). Four giant tunnel boring machines, nicknamed Sissi, Heidi, Gabi I and Gabi II, did much of the cutting.

It lies deep under the Alps, to a maximum depth of 2,450 metres, comparable to the deepest mines on Earth, and without ventilation the temperature inside the mountain reaches 46 degrees Celsius. The two tunnels are joined about every 325 metres by . It is the first flat route through the Alps, at a maximum elevation of 549 metres above sea level, the same as the city of Bern.

2,450 m

maximum depth of the tunnel under the mountains, the deepest railway tunnel in the world

Why dig so far down? The tunnel is meant to shift from trucks to trains, which reduces environmental damage and deadly road crashes. The old route, the Gotthard railway line, was a winding mountain route opened in 1882 that was operating at its capacity. The new tunnel is called a base tunnel because it bypasses most of that line.

The human cost was real. Nine workers died during construction, and a shrine to Saint Barbara, the patron of miners, stands inside the tunnel as a memorial.

Quiz me

0/3

  1. 1.Why did the builders of the Gotthard Base Tunnel dig four access tunnels?
  2. 2.Why is the Gotthard Base Tunnel called a 'base' tunnel?
  3. 3.What is the main purpose of the Gotthard Base Tunnel?

Recap

To dig a giant tunnel quickly, open many working faces at once with access tunnels and shafts, then join the tubes with cross-passages.

๐Ÿ’ก A trick to remember it ยท Don't dig it end to end: open the mountain from the middle with shafts.

Surprising fact ยท Inside the mountain the temperature reaches 46 degrees Celsius without ventilation, and a shrine to Saint Barbara, patron of miners, stands inside.
