How do you land a rover on Mars in the "seven minutes of terror"?

When Perseverance touched down in 2021, the news took 11 minutes to reach Earth. The whole landing, from atmosphere to ground, lasts about seven.

Guess first

?

signal travel time from Mars when Perseverance landed in February 2021

Which one is it?

By doing almost everything automatically, in a single seven-minute sequence of heat shield, parachute, rockets and a hovering "". Radio signals from Mars take minutes to reach Earth, and as long again to come back, so any command sent in reply would arrive after the landing is over. Engineers nickname this phase "seven minutes of terror": the spacecraft is on its own once it enters the Martian atmosphere.

The timing is the heart of it. The one-way delay between Mars and Earth ranges from 4 to 22 minutes depending on where the planets are, and averages 12.5. When Perseverance landed on 18 February 2021, the news took 11 minutes to arrive. Try the slider: at Perseverance's 11 minutes, the descent was over before Earth even heard it had begun, and even at the shortest delay a reply would need about 8 minutes for the round trip, longer than the whole landing.

Try it

When does Earth hear about the landing?

0816243202468minutes after the spacecraft enters the atmosphereminute at which Earth learns of it

y = 1x + 11

Challenge · Set the delay to 11 minutes, as for Perseverance. At what minute does Earth learn that the descent has ended, seven minutes after entry?

A simple model: an event on Mars reaches Earth after the one-way delay, so the line is the event time plus that delay. The slider spans the 4 to 22 minutes quoted for Mars; a reply takes as long again to get back.

The landing is tricky because Mars's atmosphere is too thin for a parachute alone to do the job, yet thick enough to cause stability trouble for rockets. So the craft uses a chain of tools. An with a heat shield leads the way in. A parachute opens while the craft is still moving at supersonic speed. Then, under 320 km/h and about 1.9 km up, the rover and a rocket-powered descent stage drop away from the parachute.

The final trick is the . Rockets on the descent stage hold it above the ground while it lowers the rover on cables. Once touchdown is confirmed, the cables are cut and the stage flies off to crash a safe distance away. Both Curiosity and Perseverance landed this way, and Perseverance came down within five metres of its target.

Quiz me

0/3

  1. 1.Why can't mission control steer a rover through its Mars landing?
  2. 2.Why does a Mars lander need parachute and rockets rather than a parachute alone?
  3. 3.What does a sky crane do during the final moments of the landing?

Recap

Radio takes minutes to cross from Mars, so the landing is over before Earth can intervene.

💡 A trick to remember it · Seven minutes to land, eleven for the news: by the time Earth hears "entry", the rover is already down, or not.

Surprising fact · Perseverance's parachute hid the binary message "dare mighty things" in its pattern.

Sources (5)

No source, no claim. Every fact in this lesson (16 claims) cites at least one of these.

  1. [1]A new 7 minutes of terror: See the nail-biting Mars landing of NASA's Perseverance rover in this video · Live Science
  2. [2]Mars Science Laboratory · Wikipedia
  3. [3]Mars landing · Wikipedia
  4. [4]Mars 2020 · Wikipedia
  5. [5]Perseverance (rover) · Wikipedia
