Who is really flying a modern airliner, the pilot or the computer?

In a fly-by-wire airliner the pilot's stick does not move the control surfaces: it sends a request to computers that decide how to move them.

▶ Start the story

A modern airliner is flown by both, and the split of work is the point. On a fly-by-wire aircraft the pilot's stick or yoke no longer moves cables to the control surfaces. The movements are converted to electronic signals, and flight control computers decide how to move each control surface to give the ordered response. The computers stabilise the aircraft without the pilot's involvement and try to prevent the pilot from operating outside the aircraft's safe performance envelope.

How fly-by-wire turns a stick movement into flight
  1. Step 1: Pilot moves the stick

    The movement becomes an electronic signal

  2. Step 2: Computers decide

    They work out how to move each control surface

  3. Step 3: move the surfaces

    Elevators, ailerons and rudder respond

  4. Step 4:

    Limits keep the aircraft inside safe performance

The is the older partner. It controls the aircraft's path without constant intervention from a human operator, but it does not replace the humans: it lets them focus on broader aspects such as the trajectory, the weather and on-board systems. The first gyroscopic autopilot was built by Sperry in 1912, and in 1914 Lawrence Sperry showed it off in Paris by flying with his hands away from the controls, in full view of onlookers.

Fly-by-wire came to airliners later. The Airbus A320 began service in 1988 as the first mass-produced airliner with digital fly-by-wire controls. Since the loss of all flight control computers would make an aircraft uncontrollable at once, such systems use computers or a mechanical or hydraulic backup.

The hardest moments are when the automation steps back. On 1 June 2009, Air France Flight 447, an Airbus A330, crashed into the Atlantic, killing all 228 on board. Investigators concluded that ice crystals likely blocked its , so the speed readings were inconsistent and the disconnected. The crew reacted incorrectly, and the aircraft entered a stall that the pilots failed to correct. The lesson is that a good partnership needs the human to know exactly what the machine is, and is not, doing.

Quiz me

0/3

  1. 1.What does a fly-by-wire system do with the pilot's stick movements?
  2. 2.Why do most fly-by-wire systems have redundant computers or a mechanical backup?
  3. 3.What happened first on Air France Flight 447, according to the investigators?

Recap

The pilot asks, the computer moves the surfaces, and the pilot must still be ready when the computer lets go.

💡 A trick to remember it · The computer is a very good co-pilot who still needs a captain who understands it.

Surprising fact · An F-8 using Apollo hardware flew the first digital fly-by-wire without a mechanical backup in 1972.
