How does a nuclear power plant turn splitting atoms into electricity?

It is a steam power plant with a very strange furnace: a chain reaction that must be held at exactly one.

Guess first

?

energy from splitting one uranium-235 atom compared with burning one carbon atom

Which one is it?

A nuclear power plant is, at heart, a very unusual way to boil water. Splitting uranium atoms releases heat, the heat makes steam, and the steam spins a connected to a generator. What is unusual is the furnace.

The trick is the . When a uranium-235 atom splits, it releases energy and a few neutrons. If those neutrons split more atoms, which release more neutrons, the reaction sustains itself. The scale is startling: splitting one uranium-235 atom frees about 100 million times the energy of burning one carbon atom. One kilogram of uranium-235 releases as much energy as burning about 2.7 million kilograms of coal.

From split atom to socket
  1. Step 1: Atoms split

    Uranium-235 releases heat and neutrons

  2. Step 2:

    Neutrons split more atoms, held near one for one

  3. Step 3: Steam

    Heat carried away by coolant boils water

  4. Step 4:

    Steam spins a

  5. Step 5: Generator

    The spinning shaft makes electricity

Left alone, a would grow exponentially, so a reactor is built to keep it balanced at exactly one new split for each split. Two ingredients do the balancing. A , usually ordinary water, slows the speedy neutrons so they are likely to split the next atom. , made of -absorbing elements such as boron, slide in and out of the core to soak up neutrons and turn the reaction up or down.

Fission was only understood in 1938 and 1939, when Otto Hahn and Fritz Strassmann found it and Lise Meitner and her nephew Otto Frisch explained it. Just four years later, on 2 December 1942, Enrico Fermi's team made the first self-sustaining under the stands of a university stadium in Chicago. In 2023, nuclear plants supplied about 9 percent of the world's electricity.

Quiz me

0/3

  1. 1.Why does a reactor need a moderator?
  2. 2.In a nuclear power plant, what actually spins the turbine that drives the generator?
  3. 3.What do control rods do?

Recap

Splitting atoms makes heat, a moderator keeps the chain reaction going, control rods keep it steady, and from there it is a steam power plant.

💡 A trick to remember it · The moderator is the catcher's mitt that slows neutrons down; the control rods are the brake that soaks them up.

Surprising fact · Splitting one uranium-235 atom frees about 100 million times the energy of burning one carbon atom.
